Steinway & Sons Model M Medium Grand Piano

At 5' 7" (170 cm) in length, the Model M Medium Grand piano's rich tone, responsive action and manageable size makes it perfect for conservatories, and many homes as well. The Model M is also available as a STEINWAY SPIRIO, the world’s finest high resolution player piano.

Dimensions

Length: 5' 7" (170 cm)
Width: 57¾" (147 cm)
Net Weight: 603 lbs (274 kg)

Braces

3 solid spruce with a volume of 1,196 cu. in. (19,597 cm³); Spruce provides tensile strength with less weight. Maple dowels fasten braces to rim & crossblock producing a single homogenous foundation upon which is built the tonal component. Note: Treble bell is not required in smaller grands of lesser tensions.

Scale

Overstrung; combination agraffe; Front AND rear duplex.
Tension: 33,823 lbs. (15,040 kg)

Ribs

Made from durable, resinous sugar pine to assure strong and constant support of string down-bearing on the soundboard; rib ends are hand-fitted.

Tuning Pins

Premium blued steel; rust-resistant, nickeled heads.

Strings

Treble: eleven whole & one-half sizes from high-tensile Swedish steel.
Bass: Swedish steel core wire wound with pure copper.
Longest: Agraffe/bridge: 49¼" (125 cm)

Hammers

Premium wool top felt and under felt; treated to resist insects and moisture. Compression-wired to maintain permanent shape. Hornbeam hammer moldings and shanks.

Dampers

Horizontal-cut premium wool for effective dampening with maple heads for endurance.

Keys

European spruce, individually weighed-off. Chip-proof, stain-resistant coverings for naturals; slip-proof, abraded ebonized sharps. Durable Linden wood buttons reinforce keys over balance rail, permitting maximum tonal power with every strike. Longest key: 19" (48.3 cm).

Keybed

Made from planks of quarter-sawn spruce. Horizontal and vertical birch planks present a vented system for humidity escapement. Crowned and reverse-crowned action frame gives a snug fit, intensifies key movement and prevents “slapping” during heavy playing. Large maple dowel ends provide a solid mount for adjustable brass touch-regulating screws. Thickness: 1¾” (4.45 cm).

Pedals

Heavy, solid brass. Soft, sustaining, and full sostenuto.

Interested in this piano?

We are an exclusive Steinway dealer in and around the Midwest. Enter your name and email and a piano specialist will get back to you to talk through your options.

Spirio & Spirio | r

Legendary Performances | Masterpiece of Artistry & Engineering

The Steinway & Sons Spirio stands as the pinnacle of high-resolution player pianos, merging artistry and cutting-edge engineering into one stunning instrument. With Spirio, you can experience the performances of renowned pianists, rendered with such precise nuance, power, and passion that they are virtually indistinguishable from a live performance.

While recordings allow us to appreciate the skill of professional musicians, nothing matches the experience of hearing a performance directly from the piano, delivered with breathtakingly accurate dynamics.

Steinway Spirio | r

Play | Record | Listen | Edit

The Steinway Spirio | r is the world’s finest high resolution player piano now capable of live performance capture and playback. A revolutionary blend of artistry, craftsmanship, and technology, Spirio | r provides powerful new tools of expression and new ways to access, share and experience performance.

Available in models B, D, and M.
